CS-series CPU Unit type: CS1G/H-CPU-EV1, CS1G/H-H
Connect to the built-in RS-232C port of the CPU Unit, or the RS-232C port of the
Communications Board. Note that the connection to a peripheral port must be made via an
RS-232C adapter (CS1W-CN118) specially designed for connecting to a peripheral port.
PLC Setup
When connecting to a CS-series CPU Unit, set the following communications conditions for
the PLC Setup area. Since the settings shown below are the PLC default settings for the
CPU Unit, no change to the PLC Setup is necessary as long as the communications speed
is maintained at 9600 bps.
Item Setting at Host
Communications speed Set the same baud rate as set at the NS-series PT (See note.)
Stop bits 2 stop bits
Parity Even
Data length ASCII 7 bits
Unit No. for the host link 00
Note: Set the Host Link communications speed (baud rate) to 9600 bps or 19200 bps with
the Communications Setting menu item in the CX-Designer and the System Menu for
the NS-series PT. For details, refer to 1-4 Settings for Host Link.
When the communications speed is set to 19200 bps., the PLC Setup of the CPU
Unit need to be changed.
Either set the PLC Setup directly from a Programming Device (Programming Console), or
transmit the PLC Setup made at a Programming Device (CX-Programmer) to the CPU Unit.
For details on PLC Setup, refer to the SYSMAC CS series Operation Manual (W339-E1-@).
When using the built-in RS-232C port of CS1G/H
Word # Writing Value Settings
160 8000 Host link mode, data length 7 bits, 2 stop bits, even parity
0000 Communications speed: 9600 bps. 161
0007 Communications speed: 19200 bps.
166 0000 Unit #00
When using the peripheral port of CS1G/H
Word # Writing Value Settings
144 8000 Host link mode, data length 7 bits, 2 stop bits, even parity
0000 Communications speed: 9600 bps. 145
0007 Communications speed: 19200 bps.
150 0000 Unit #00
Setting the Front Switches
Set the CPU Unit DIP switches to 4 or 5 in accordance with the port the NS-Series PT is
connected to.
