CVM1/CV-series PLCs
PLC model
Common I/O Area (CIO)
Holding Relay (HR)
(See note 1.)
Auxiliary Relay (AR)
Link Relay (LR)
Timer/Counter Area
(TIM/CNT)
Data Memory Area (DM)
EM Area (Current bank)
(EM) (See note 2.)
CV500
CVM1-CPU01-V
@
00000
to
02555
- 00000
to
00511
- 00000
to
00511
00000
to
08191
-
CVM1-CPU11-V@
00000
to
02555
- 00000
to
00511
- 00000
to
01023
00000
to
09999
-
CV1000
CV2000
CVM1-CPU11-V
@
CVM1-CPU21-V
@
00000
to
02555
- 00000
to
00511
- 00000
to
01023
00000
to
09999
-
Note 1: The HR Area is included in the CIO Area. To use the HR Area, specify the CIO Area.
2: Do not use this area for creating screens. It cannot be used with Host Link
communications.
OMRON CS/CJ-series PLCs
PLC model
Common I/O Area
(CIO)
Holding Relay
(HR)
Auxiliary Relay
(AR)
Link Relay (LR)
Timer/Counter
Area (TIM/CNT)
Data Memory
Area (DM)
EM Area (Current
bank)
(
See note 1.
)
00000
to
06143
00000
to
00511
00000
to
00959
- 00000
to
02047
00000
to
09999
00000
to
09999
Work Area (WR)
(See note 2.)
CS1G/H(-H)
CJ1G/H(-H)
CJ1M
CP1L
CP1H
CJ2H
CJ2M
-
Note 1: The EM Area cannot be specified for the CJ1M.
2: Do not use this area for creating screens. It cannot be used with Host Link
communications.
