6-3SectionOperation Modes and the System Menu
106
The items displayed in the system menu and their functions are as follows.
Menu Item Function
Quit Clear the System Menu screen and return to the RUN mode
screen.
Transmit Mode Display the Transmit Mode screen to allow transmission for
screen data between the NT Support Tool and the NT21. For
details on transmission of screen data, refer to 6-6 Transmitting
the Screen Data (page 123).
Maintenance Mode Display the Maintenance Mode menu to allow system mainte-
nance of the NT21, and various NT21 settings.
Expansion Mode Display the Expansion Mode menu to perform selection of the
expansion functions supported by the NT21. The following ex-
pansion functions are supported:
• Version Display
Displays the version of system program, the date it was
created, and the PT model. For details, refer to 6-13 Version
Display.
• Programming Console Function
Allows the NT21 to be used as a Programming Console for a
CS1G/CS1H, CS1G-H/CS1H-H, CJ1G, CPM1, CPM2A,
CPM2C, CQM1, CQM1H, C200HX/HG/HE(-Z), or SRM1.
For details, refer to 6-12 Programming Console Function.
The following functions can be executed in the System Installer mode.
• Setting the display language
• Clearing and installing system programs
• Disabling/enabling display of the System Menu.
• Disabling/enabling writing to the screen data memory
• Clearing screen data
For details on these functions, refer to 6-5 Operations in the System Installer
Mode (page 118).
Items in the System
Menu
Functions of the System
Installer Mode
To Next Page
