Appendix ASpecifications
191
Specifications for High-speed 1:N NT Link Communications
Item Specification
Communications standard EIA RS-232C
Connector 9-pin D-SUB connectors (female) (serial ports A and B)
Number of Units connected
1:1 to 8
Transmission distance Max. 15 m
*
* NT-AL001 or NS-AL002 Link Adapters are required to connect two or more PTs. When using Link Adapters, the
specifications are as follows:
• RS-232C cable: Max. 2 m (Not required with the NS-AL002)
• RS-422A/485 cable: Total length 500 m max.
Specifications for Memory Link Communications
Item Specification
Communications standard EIA RS-232C
Communications settings
Start-stop synchronization
Baud rate:
1,200, 2,400, 4,800, 9,600, 19,200, or 38,400 bps
Data length: 7, 8 bits
Stop bits: 1, 2 bits
Parity: None, even, odd
Flow control: None, RS/CS, XON/XOFF
Response: Presence/absence
Connector 9-pin D-SUB connectors (female) (serial ports A and B)
Number of Units connected 1:1
Transmission distance Max. 15 m*
Communications protocol Memory link
* When using NT-AL001 or NS-AL002 Link Adapter, specifications are as follows:
• RS-232C: Max. 2 m (Not required with the NS-AL002)
• RS-422A: Max. total length 500 m
Specifications for Bar Code Reader Communications
Item Specification
Communications standard EIA RS-232C
Communications settings
Start-stop synchronization
Baud rate: 4,800, 9,600, or 19,200 bps
Data length: 7, 8 bits
Stop bits: 1, 2 bits
Parity: None, even, odd
Flow control: RS/CS
Connector 9-pin D-SUB connector (female) (serial port A)
Number of Units connected 1:1
Transmission distance Max. 15 m
Communications protocol Non-protocol mode
Data format
[STX] Data (0 to 40 bytes) [ETX]
