Appendix BExternal Dimensions and Mounting Dimensions
194
Cable Connection Dimensions
Units: mm (inch)
28 (1.10)
51.1 (2.01)
28 (1.10)
19.5
(0.77)
52.5 (2.07)
45
(1.77)
39.5 (1.56)
58.3 (2.30)
72.6 (2.86)
Units: mm (inch)
28 (1.10) 28 (1.10)
19.5
(0.77)
52.5 (2.07)
43.6 (1.72)
39.5
(1.56)
72.6 (2.86)
