7 SSI Input Units
NX-series Position Interface Units User’s Manual (W524)
7-9 Functions
7
7-9-1 Parameters
Status Data Length This is the data length of the
status data.
0 to 32 Bits 0 P. 7-42
Leading Bits This is the number of leading
bits for the SSI data.
0 to 31 Bits 0 P. 7-52
Parity Check 0: No check
1: Even parity check
2: Odd parity check
0 to 2 --- 0 P. 7-53
Encoder Resolution This is the resolution for sin-
gle-turn data.
0 to
4294967295
--- 0 P. 7-42
Coding Method 0: No change
1: Output binary codes.
2: Change gray codes to
binary codes.
3: Change binary codes to
present values.
4: Change gray codes to
present values.
0 to 4 --- 3 P. 7-44
Position Variation
Limit
This is the limit to the change
in the position from the previ-
ous position data.
0 to
2147483647
--- 0 P. 7-55
Encoder Count
Direction
0: Not to invert the sign
1: Invert the sign
0 or 1 --- 0 P. 7-50
Parameter name Function Setting range Unit Default Reference
