10 Troubleshooting
NX-series Position Interface Units User’s Manual (W524)
10-3 Checking for Errors and
Troubleshooting on the Sysmac
10
10-3-2 Event Codes for Errors and Troubleshooting Procedures
Event name External Input Setting Error Event code 3510 0000 hex
Meaning A setting for an external input is not correct.
Source
Depends on where the Sysmac
Studio is connected and the sys-
tem configuration.
Source details
NX Unit
Detection
timing
When power is
turned ON to
the NX Unit
Error
attributes
Level
Minor fault
Recovery
Restart the NX
Unit.
Log category
System
Effects User program
Continues.
Operation
External inputs are disabled.
The following bit changes to FALSE: Ch External
Input Enabled bit in the Reset/External Input Status.
Sys-
tem-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The same function (other than a
general-purpose input) is
assigned to more than one of the
external inputs (I0 to I2).
Except for general-purpose inputs,
do not assign the same function to
more than one external input.
Except for general-purpose inputs,
do not assign the same function to
more than one external input.
Attached
information
None
Precautions/
Remarks
None
