Omron NX-EC0112 User Manual

10 Troubleshooting
10 - 20
NX-series Position Interface Units User’s Manual (W524)
Event name NX Unit Clock Not Synchronized Error Event code 80240000 hex
Meaning An error occurred in the clock information between the EtherCAT Coupler Unit and the NX Unit.
Source
Depends on where the Sysmac
Studio is connected and the sys-
tem configuration.
Source details
NX Unit
Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Restart the NX
Unit.
Log category
System
Effects User program
Continues.
Operation
The NX Unit will continue to operate.
Input data: Updating input values stops.
Output data: The external outputs are turned OFF.
The pulse output value depends on the Load Rejec-
tion Output Setting.
Sys-
tem-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
There is a hardware error in the
NX Unit.
If the error occurred in only a spe-
cific NX Unit in the Slave Terminal,
replace the NX Unit.
If the error occurred in all of the
NX Units on the Slave Terminal
except for the System Units,
replace the EtherCAT Coupler
Unit.
None
There is a hardware error in the
EtherCAT Coupler Unit.
Attached
information
None
Precautions/
Remarks
None
