Omron NX-EC0112 User Manual

A - 39
Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-2 Incremental Encoder Input Units
• Set this object to the time window for pulse rate measurement.
• Set this parameter to 0 to disable pulse rate measurement.
• Set this object to the average processing times for pulse rate measurement.
• Set this object to 0 to disable average processing.
• The following table shows the settings for the Edge Detection Method object.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5004 --- Time Window --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-EC0112, NX-EC0122, NX-EC0132, or NX-EC0142 are 1. The values for the NX-EC0212 or
NX-EC0222 are 2.
*1 --- USINT RO No ---
01 Ch1 Time Window 0 0 to 65535 ms UINT RW No N
02
Ch2 Time Window
*2
*2. This object does not exist on the NX-EC0112, NX-EC0122, NX-EC0132, and NX-EC0142.
0 0 to 65535 ms UINT RW No N
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5005 --- Average Processing
Times
--- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-EC0112, NX-EC0122, NX-EC0132, or NX-EC0142 are 1. The values for the NX-EC0212 or
NX-EC0222 are 2.
*1 --- USINT RO No ---
01 Ch1 Average Process-
ing Times
0 0 to 100 Times USINT RW No N
02 Ch2 Average Process-
ing Times
*2
*2. This object does not exist on the NX-EC0112, NX-EC0122, NX-EC0132, and NX-EC0142.
0 0 to 100 Times USINT RW No N
Index
(hex)
Subin-
dex
(hex)
Object name Default
Data
range
Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5006 --- Edge Detection Method --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-EC0112, NX-EC0122, NX-EC0132, or NX-EC0142 are 1. The values for the NX-EC0212 or
NX-EC0222 are 2.
*1 --- USINT RO No ---
01 Ch1 Edge Detection
Method
0 0 to 3 --- USINT RW No Y
02 Ch2 Edge Detection
Method
*2
*2. This object does not exist on the NX-EC0112, NX-EC0122, NX-EC0132, and NX-EC0142.
0 0 to 3 --- USINT RW No Y
Set value Description
0 Disable the function.
1 Measure every rising edge.
2 Measure every falling edge.
3 Measure every rising and falling edge.
