5 I/O Refreshing
NX-series Digital I/O Unit User’s Manual (W521)
5-2 I/O Refreshing Methods
5
5-2-4 Free-Run Refreshing
 Digital Input Units
This uses the I/O ports of the input values.
Four-point Input Units
Eight-point Input Units
Sixteen-point Input Units
Thirty-two-point Input Units
I/O Port
I/O port name Type R/W Name Description
Default
value
Input Bit 00 BOOL RO Input Bit 00 The input value for input bit 00. FALSE
Input Bit 01 BOOL RO Input Bit 01 The input value for input bit 01. FALSE
Input Bit 02 BOOL RO Input Bit 02 The input value for input bit 02. FALSE
Input Bit 03 BOOL RO Input Bit 03 The input value for input bit 03. FALSE
I/O port name Type R/W Name Description
Default
value
Input Bit 8 bits BYTE RO Input Bit 8 bits The input values for 8 bits. 00 hex
I/O port name Type R/W Name Description
Default
value
Input Bit 16 bits WORD RO Input Bit 16 bits The input values for 16 bits. 0000 hex
I/O port name Type R/W Name Description
Default
value
Input Bit 32 bits DWORD RO Input Bit 32 bits The input values for 32 bits.
00000000
hex
