3 Part Names and Functions

3 - 12

NX-series Digital I/O Unit User’s Manual (W521)

3-2-2 IN/OUT Indicator

Color Status Description

Yellow Lit Digital I/O is ON

- Not lit Digital I/O is OFF

This indicator shows the signal I/O status of each terminal of the Digital I/O Units.

For Digital Mixed I/O Units, the indicator shows as follows.

OUT indicator

IN indicator
