8 Digital Mixed I/O Units
NX-series Digital I/O Unit User’s Manual (W521)
8-3 List of Settings
8
8-3-1 Input Settings
8-3 List of Settings
The following are the setting descriptions, setting ranges, and default values of the functions that can
be used in the Digital Mixed I/O Units.
The settings are reflected after the Unit is restarted.
Precautions for Safe Use
The Unit is required to restart after the transfer of Unit operation settings on the Sysmac Studio
is completed. Always sufficiently check the safety at the connected devices before you transfer
the Unit operation settings.
This section describes the allocable I/O data in the Digital Mixed I/O Units.
 Sixteen-point Input Units
*1. The descriptions of Input Filter Value Setting are as follows.
8-3-1 Input Settings
NX Units in Free-Run Refreshing or Synchronous I/O Refreshing
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Input Filter Value Setting Set the filter time of input
signal.
*1
*1 *1
 5000
hex
01 hex P. 6-14
Input Filter Mode Setting Set the operating mode
for the filter.
*2
*2 *2
 02 hex P. 6-14
Set
value
Setting description Default value Setting range
0 No Filter 3 0 to 11
1 0.25 ms
2 0.5 ms
31 ms
42 ms
54 ms
68 ms
716 ms
832 ms
964 ms
10 128 ms
11 256 ms
