6 - 5
6 Digital Input Units
NX-series Digital I/O Unit User’s Manual (W521)
6-2 Specifications of I/O Data
6
6-2-1 Allocable I/O Data
 Eight-point Input Units
 Sixteen-point Input Units
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Input Bit 8 bits The input values for 8
bits.
The following 8 BOOL
data are included.
BYTE 00 hex Input Bit 8
bits
6001 hex 01 hex
Input Bit 00 The input value for input
bit 00.
BOOL FALSE Input Bit 00
Input Bit 01 The input value for input
bit 01.
BOOL FALSE Input Bit 01
Input Bit 02 The input value for input
bit 02.
BOOL FALSE Input Bit 02
Input Bit 03 The input value for input
bit 03.
BOOL FALSE Input Bit 03
Input Bit 04 The input value for input
bit 04.
BOOL FALSE Input Bit 04
Input Bit 05 The input value for input
bit 05.
BOOL FALSE Input Bit 05
Input Bit 06 The input value for input
bit 06.
BOOL FALSE Input Bit 06
Input Bit 07 The input value for input
bit 07.
BOOL FALSE Input Bit 07
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Input Bit 16 bits The input values for 16
bits.
The following 16 BOOL
data are included.
WORD 0000 hex Input Bit 16
bits
6002 hex 01 hex
Input Bit 00 The input value for input
bit 00.
BOOL FALSE Input Bit 00
Input Bit 01 The input value for input
bit 01.
BOOL FALSE Input Bit 01
•
•
•
Input Bit 15 The input value for input
bit 15.
BOOL FALSE Input Bit 15
