7 - 5
7 Digital Output Units
NX-series Digital I/O Unit Users Manual (W521)
7-2 Specifications of I/O Data
7
7-2-1 Allocable I/O Data
Four-point Output Units
Eight-point Output Units
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Output Bit 00 The output set value for
output bit 00.
BOOL FALSE Output Bit 00 7000 hex 01 hex
Output Bit 01 The output set value for
output bit 01.
BOOL FALSE Output Bit 01 02 hex
Output Bit 02 The output set value for
output bit 02.
BOOL FALSE Output Bit 02 03 hex
Output Bit 03 The output set value for
output bit 03.
BOOL FALSE Output Bit 03 04 hex
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Output Bit 8 bits The output values for 8
bits.
The following 8 BOOL
data are included.
BYTE 00 hex Output Bit 8
bits
7001 hex 01 hex
Output Bit 00 The output set value for
output bit 00.
BOOL FALSE Output Bit 00
Output Bit 01 The output set value for
output bit 01.
BOOL FALSE Output Bit 01
Output Bit 02 The output set value for
output bit 02.
BOOL FALSE Output Bit 02
Output Bit 03 The output set value for
output bit 03.
BOOL FALSE Output Bit 03
Output Bit 04 The output set value for
output bit 04.
BOOL FALSE Output Bit 04
Output Bit 05 The output set value for
output bit 05.
BOOL FALSE Output Bit 05
Output Bit 06 The output set value for
output bit 06.
BOOL FALSE Output Bit 06
Output Bit 07 The output set value for
output bit 07.
BOOL FALSE Output Bit 07
