7-2 Specifications of I/O Data
7
7-2-1 Allocable I/O Data
 Two-point Output Units
NX Units in Output Refreshing with Specified Time Stamp
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Unit
Output Bit 00 The output set
value for output bit
00.
BOOL FALSE Output Bit 00 7000 hex 01 hex 
Output Bit 01 The output set
value for output bit
01.
BOOL FALSE Output Bit 01 02 hex 
Output Bit 00 Time
Stamp
The specified oper-
ation time for out-
put bit 00. If the
value is 0, the out-
put is refreshed
immediately.
ULINT 0 Output Bit 00
Time Stamp
7010 hex 01 hex ns
Output Bit 01 Time
Stamp
The specified oper-
ation time for out-
put bit 01. If the
value is 0, the out-
put is refreshed
immediately.
ULINT 0 Output Bit 01
Time Stamp
02 hex ns
Output Bit 00 Out-
put Status
The specified time
output status for
output bit 00.
BOOL FALSE Output Bit 00
Output Sta-
tus
6011 hex 01 hex 
Output Bit 01 Out-
put Status
The specified time
output status for
output bit 01.
BOOL FALSE Output Bit 01
Output Sta-
tus
02 hex 
