Appendices
A - 88
NX-series Digital I/O Unit User’s Manual (W521)
*1. The default value and data range for Number of Entries are as follows.
*2. The meaning of the set values for Input Bit  Trigger Setting is as follows.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5005  Time Stamp (Trigger Set-
ting)
 
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Input Bit 00 Trigger Setting FALSE TRUE or
FALSE
*2
 BOOL RW Not
pos-
sible
Y
02 Input Bit 01 Trigger Setting FALSE  BOOL RW Not
pos-
sible
Y
03 Input Bit 02 Trigger Setting FALSE  BOOL RW Not
pos-
sible
Y
04 Input Bit 03 Trigger Setting FALSE  BOOL RW Not
pos-
sible
Y
NX Units Default value Data range
NX-ID3344/ID3444 4 4 (fixed)
Other models 0 0 (fixed)
Set value Meaning
FALSE Rising Edge
TRUE Falling Edge
