Appendix A
A-67
A
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
DB_GetConnectionStatus (Get DB Connection Status)
When the instruction was executed while the DB Connection Service was stopped due to an error
When the instruction was executed after the DB Connection Service was shut down or while the DB
Connection Service was being shut down
When the DB Connection name specified in the DBConnectionName input variable is not set in any
DB Connection Settings
When the DBConnectionName input variable is a text string consisting of NULL characters (16#00)
only
When a space character is included in the text string specified for the DBConnectionName input
variable
When the DBConnectionName input variable does not end in NULL.
When more than 32 DB Connection Instructions were executed at the same time
Sample Programming
This section gives sample programming for the following operations.
Get the status of the DB Connection when the trigger variable changes to TRUE.
Change the value of the Warning variable to TRUE when the spool usage has exceeded 80%.
Ladder Diagram
Main Variables
DB_GetConnectionStatus_instance DB_GetConnectionStatus --- Instance of DB_GetConnectionStatus
Trigger BOOL FALSE Variable used as a trigger for getting
the status of the DB Connection
Operating BOOL FALSE The DB_GetConnectionStatus
instruction is executed when this
OperatingEnd BOOL FALSE This variable changes to TRUE when
the DB_GetConnectionStatus
instruction is completed.
Instance of RS instruction
MyStatus _sDBC_CONNECTION_STATUS --- This variable is assigned to the
ConnectionStatus output variable
from
DB_GetConnectionStatus_instance.
Warning BOOL FALSE This variable changes to TRUE when
the Spool usage has exceeded 80%.
GetConnectionStatus_OK BOOL FALSE This variable changes to TRUE when
the DB_GetConnectionStatus
instruction is completed normally.
DB Connection Instructions
To Next Page
