Appendix B
B-3
B
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
B-1 Task Design Procedure
B-1-1 Startup Time of DB Connection Service
 NJ101-1020
DB type Percentage of task
execution time
*
Reference value for startup time of the DB
Connection Service (Average)
Oracle
50%
75.59 s
60%
89.31 s
SQL Server
50%
56.36 s
60%
67.17 s
DB2
50%
61.90 s
60%
73.35 s
MySQL
50%
54.46 s
60%
66.83 s
Firebird
50%
57.61 s
60%
70.98 s
PostgreSQL
50%
63.61 s
60%
76.63 s
* Percentage of task execution time on the Task Execution Time Monitor of Sysmac Studio.
The following table shows the measurement conditions and items.
Measurement conditions
Description
Item
Subitem
CPU Unit Task composition Primary periodic task only
Task period: 1 ms
System configuration Basic
configuration
 No EtherCAT network
 No CJ-series Units
 USB connection with Sysmac Studio
Network
configuration
 No connection with other controllers

No connection with HMI
Precautions for Correct Use
 The DB Connection Service is executed as a system service.
Therefore, the execution time of each processing may require time if the startup processing of
the DB Connection Service and other system service processing are executed at the same
time.
 The guidelines for the system service execution time ratio depend on the models. Therefore,
the measurement condition of the task execution time ratio varies depending on the models.
Refer to B-1-4 Guideline for System Service Execution Time Ratio for details of the guidelines.
