1 Introduction to the DB Connection Service
1-10
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
STEP 4 Creating a Structure for DB Access
Refer to 3-2 Creating a
Structure Data Type.
Create a structure data type for DB access. The structure members must satisfy the following
conditions.
 Member names are the same as corresponding column name of the table to access.
 Members’ data types match the data type of corresponding column of the table to access.
STEP 5 Creating a Variable Using above Structure
Refer to 3-3 Creating a
DB Map Variable.
Create a variable called “DB Map Variable” using the structure data type created in STEP 4.
STEP 6 Programming using DB Connection
Instructions
Refer to 3-4 Specifying
the Table and Apply the
Mapping and 3-5
Programming and
Transfer.
1.
Initial Processing
1-1. Write a DB_ControlService (Control DB Connection Service) instruction.
(This instruction is not required if you set the DB Connection Service to auto start in the DB
Connection Settings.)
1-2. Write a DB_Connect (Establish DB Connection) instruction.
1-3. Write a DB_CreateMapping (Create DB Map) instruction.
The DB Map Variable is mapped with the columns of the table to access and registered as
a variable subject to the record processing.
2. Processing during Operation
*1
2-1. Write DB_Insert (Insert DB Record), DB_Update (Update DB Record), DB_Select
(Retrieve DB Record), and other instructions.
3. End Processing
3-1. Write a DB_Close (Close DB Connection) instruction.
4. Power OFF Processing
*2
4-1. Write a DB_Shutdown (Shutdown DB Connection Service) instruction.
*1 When you continuously execute DB_Insert (Insert DB Record), DB_Update (Update DB
Record), DB_Select (Retrieve DB Record), and other instructions, repeat the 2. Processing
during Operation.
*2 Be sure to execute a DB_Shutdown (Shutdown DB Connection Service) instruction before
you turn OFF the power supply to the system. If the power supply is turned OFF without
executing a DB_Shutdown (Shutdown DB Connection Service) instruction, the Operation
Log file may be corrupted or its contents may be lost.
