Omron OMNUC U Series

1-5
1-3 Servo Driver Nomenclature
H Front View
Terminal block
CN4: Not used
Power supply indicator
Alarm indicator
CN3: Parameter Unit connector
CN1: Control I/O connector
CN2: Encoder connector
PWR
ALM
Introduction Chapter 1
