VISUAL INDEX
For users who wish to operate soon.
- The
following portions of
this manual provide the minimum information required for operation.
Be
sure you fully understand at least the
information in these portions before attempting opera
-
tion.
Chapter
2 System Design and Installation, and sections
3-1,
3-2,
3-3,
3-4,
3-5, and
3-6 of Chap
-
ter 3 Operation.
Instructions for jog operation using a Parameter Unit are provided in 3-6.
OMNUC U is a series of fully
software-controlled AC servo
drivers
built on advanced
OM
-
RON software servo technol-
ogy. It provides high perfor-
mance, a sensitive man-ma-
chine
interface, and economy
.
SYSMAC C200HX/HG/HE
Programmable Controller
Pulse input
Controller Connecting Cable
Chapter 5: 5-3-1
Position Control Unit
3G2A5-NC111-EV1
C500-NC113/211
Troubleshooting and Remedies
- Using Displays: Chapter 4, section 4-1
-
Protective and Diagnostic Functions: Chapter 4, section 4-2
- Troubleshooting: Chapter 4, section 4-3
SYSMAC C/CV-series
Programmable Controller
Position Control Unit
C200H-NC112 C200HW-NC113/213/413
C200H-NC211
Trial Operation and Adjustment
- Trial Operation: Chapter 3, section 3-6-1
- Auto-tuning: Chapter 3, section 3-7-1
- Manually Adjusting Gain: Chapter 3, section 3-7-2
Function Setting (Parameter Setting)
- Setting and Checking User Parameters: Chapter 3, section 3-5-1
- Electronic Gear: Chapter 3, section 3-5-3
- Magnetic and Dynamic brakes: Chapter 3, section 3-5-4
