BY35S / BY50S / BY80S / BY120S
7
45
When using the included "UPS service driver", the OS standard UPS service in Windows 2000/XP/
Server2003/XP can be used. When there is a power failure, fi les can automatically be saved and the
computer can be shut down.
1. Connect the UPS to a computer.
* Only 1 computer can be connected to the UPS
Cable: Included connection cable (USB)
2. Install the included "UPS service driver" on the computer.
Software to install: UPS service driver
How to install: Refer to the separate "UPS monitoring software installation guide".
<USB>
<USB>
<BY35S/BY50S>
<BY80S/BY120S>
Included connection cable (USB)
Connect to
USB Port
on UPS
Connector
Connect
to USB
terminal
Connector
USB
Port
Connect to
USB port
on PC
Included connection cable (USB)
Connect to
USB port
on PC
Connect
to USB
terminal
USB
Port
Connector
Connect to
USB Port
on UPS
Connector
7-2
When performing auto-save functions using
the UPS service in Windows 2000/XP/
Server2003/XP
To Next Page
