6.2 Modbus Communications
238 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Register No.
(Hex.)
Description
00D2
CPF Contents 3
bit 0 CPF32 [ASIC Startup Error]
bit 1 CPF33 [Watch-dog Eror]
bit 2 CPF34 [Power/Clock Eror]
bit 3 CPF35 [Ext A/D Conv Error]
bit 4
CPU36 [CPU-ASIC Communication Error]
bit 5
CPU37 [CPU-ASIC Communication Error]
bit 6
CPU38 [EEPROM Data Error]
bit 7
CPU39 [CPU-ASIC Communication Error]
bit 8 CPF40 [Control Circuit Error]
bit 9 CPF41 [EEPROM Memory Data Error]
bit A CPF42 [EEPROM Memory Data Error]
bit B CPF43 [EEPROM Memory Data Error]
bit C CPF44 [EEPROM Memory Data Error]
bit D CPF45 [EEPROM Memory Data Error]
bit E - F Reserved
00D3 - 00D7 Reserved
00D8
oFA0x Description (CN5-A)
bit 0 oFA00 [Option Not Compatible with Port]
bit 1 oFA01 [Option Fault/Connection Error]
bit 2 - 4 Reserved
bit 5 oFA05 [Option A/D Error]
bit 6 oFA06 [Option Communication Error]
bit 7 - F Reserved
00D9
oFA1x Description (CN5-A)
bit 0 oFA10 [Option RAM Error]
bit 1 oFA11 [Option Ope Mode Error]
bit 2 oFA12 [Drive Receive CRC Error]
bit 3 oFA13 [Drive Receive Frame Error]
bit 4 oFA14 [Drive Receive Abort Error]
bit 5 oFA15 [Option Receive CRC Error]
bit 6 oFA16 [Option Receive Frame Error]
bit 7 oFA17 [Option Receive Abort Error]
bit 8 - F Reserved
00DA Reserved
