10.5 Drive Watt Loss
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 365
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4089 65
8 165 566 731
4103 77
8 206 700 906
4140 96
5 265 849 1114
4168 124
5 400 1073 1473
4208 156
5 405 1300 1705
4250 180
5 454 1174 1628
4296 240
5 664 2021 2685
4371 302
5 843 2499 3342
4389 361
5 745 2161 2906
4453 414
2 1024 2835 3859
4568 477
2 1183 3329 4512
4675 -
- - - -
Table 10.16 Drive Watt Loss (Normal Duty: < 460 V)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002 2.1 2
39 16 55
4004 4.1 2
44 33 77
4005 5.4 2
48 31 79
4007 7.1 2
52 44 96
4009 8.9 2
42 58 100
4012 11.9 2
57 84 141
4018 17.5 2
82 144 226
4023 23.4 2
108 185 293
4031 31 2
138 222 360
4038 38 2
145 270 415
4044
44 2 168 335 503
4060
59.6 2 157 444 601
4075
74.9 2 185 527 712
4089
89.2 2 212 665 877
4103
103 2 264 766 1030
4140
140 2 393 1126 1519
4168
168 2 574 1348 1922
4208
208 2 493 1465 1958
4250
250 2 686 1738 2424
4296
296 2 805 2155 2960
4371 371 2
1022 2553 3575
4389 389 2
867 2393 3260
4453 453 2
1086 3035 4121
4568 568 2
1429 3989 5418
4675 675 2
1526 4572 6098
Table 10.17 Drive Watt Loss (Normal Duty: ≥ 460 V)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002 2.1
2 39 16 55
4004 3
2 42 25 67
4005 4.8
2 45 28 73
