10.6
Drive
Exterior
and
Mounting
Dimensions
368
SIEPYEUOQ2A01A
AC
Drive
Q2A
T
echnical
Manual
■
4031,
4038
Figure
10.2
Exterior
and
Mounting
Dimensions
Diagram
2
T
able
10.19
400
V
class
(IP20)
Model
Dimensions
mm
(in.)
Weight
kg
(lb.)
W
H
D
D1
D2
W1
W2
H1
H2
t1
t2
d
4031
180
(7.09)
300
(11.81)
202
(7.95)
134
(5.28)
68
(2.68)
140
(5.51)
140
(5.51)
284
(11.18)
8
(0.315)
1.6
(0.063)
1.6
(0.063)
M5
6
(13.23)
4038
180
(7.09)
300
(11.81)
202
(7.95)
134
(5.28)
68
(2.68)
140
(5.51)
140
(5.51)
284
(11.18)
8
(0.315)
1.6
(0.063)
1.6
(0.063)
M5
6
(13.23)
