Omron Q2A-A4018-AAA Technical Manual

2.9 Installation Methods
60 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Figure 2.66 Panel Cut-Out Dimensions
Table 2.5 Panel Cut-Out Dimensions (400 V Class)
Model
Dimensions mm (in.)
W H D1 D2 W1 W2 W3 W4 W5 W6 H1 H2 H3 H4 H5 A B d1
4002
4004
4005
4007
4009
4012
4018
*1
140
(5.51)
294
(11.57)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
16
(0.63)
3
(0.12)
- -
282
(11.10)
23
(0.91)
6
(0.24)
26
(1.02)
6
(0.24)
134
(5.28)
233
(9.17)
M5
4023
*1
140
(5.51)
294
(11.57)
138
(5.43)
73
(2.87)
102
(4.02)
102
(4.02)
16
(0.63)
3
(0.12)
- -
282
(11.10)
23
(0.91)
6
(0.24)
26
(1.02)
6
(0.24)
134
(5.28)
233
(9.17)
M5
