812 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
o2-04 Setting Drive Model
6F 2082
70 2110
72 2138
73 2169
74 2211
75 2257
76 2313
77 2360
78 2415
92 4002
93 4004
94 4005
95 4007
96 4009
97 4012
99 4018
9A 4023
o2-04 Setting Drive Model
9C 4031
9D 4038
9E 4044
9F 4060
A1 4075
A2 4089
A3 4103
A4 4140
A5 4168
A6 4208
A7 4250
A8 4296
A9 4371
AA 4389
AC 4453
AD 4568
AE 4675
■ o2-05 LCD FreqRef Mode@Home Screen
No.
(Hex.)
Name Description
Default
(Range)
o2-05
(0509)
LCD FreqRef
Mode@Home Screen
Sets the function that makes it necessary to push the button to change the frequency
reference value with the keypad when in Drive Mode.
0
(0, 1)
0 : Disabled
You must push to use the keypad to change the frequency reference value.
1 : Enabled
The frequency reference changes when you enter it with the keypad. This then changes the output frequency. It is
not necessary to push . The drive keeps the frequency reference for 5 seconds after you use and on
the keypad to change the frequency reference value.
■ o2-06 Keypad Disconnect Detection
No.
(Hex.)
Name Description
Default
(Range)
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad connection cable from the drive
or if you damage the cable while the keypad is the Run command source.
Determined by o2-09
(0, 1)
This parameter continues to operate if the keypad installed to the drive becomes disconnected.
This parameter is enabled in these conditions:
• When b1-02 = 0 [Run Comm. Sel 1 = Keypad] or b1-16 = 0 [Run Comm. Sel 2 = Keypad]
• In LOCAL Mode
0 : Disabled
The drive continues operation when it detects a keypad disconnection.
1 : Enabled
The drive stops operation, detects oPr [Keypad Connection Fault], and the motor coasts to stop when the drive
detects a keypad disconnection.
To Next Page
