12 Frequency inverters
Current suppression reactor
Reference Fig.
Dimensions (mm)
Weight
(kg)
A B B1 C D
B1509105
1 max. 78 63 - 102 - 0.85
B1509106
max. 96 60 118 1.31
B1509107 1.32
B1509108
2 120 max. 90 85 150 - 1.9
B1509109 1.93
B1509110
3 155 max. 102 95 195 - 3.8
B1504118
4 155 95 - 175 - 4.0
B1509111
3 155 max. 102 95 195 - 4.43
B1509112 110 - 5.95
B1509113
5 185 max. 125 102 160 3 6.9
B1509114 max. 140 122 10.8
B1505002
6 220 max. 115 90 205 4 17.0
B1505008
230 max. 140 107 215 5 22.0
B1505011
240 max. 150 120 235 29.0
Figure 6
earth connector M8
B1
B
C
D
A
4 mm terminal
2
earth terminal 6.3x0.8
Figure 1
A
B
C
Figure 2
A
C
B1
B
16 mm terminal
2
earth screw M5x10
(with lockwasher and washer)
Figure 3
A
B
B1
C
35 mm terminal
2
earth screw M5x10
(with lockwasher and washer)
U1
U2
V2 W2
V1 W1
A
Figure 5
C
D
B
B1
earth connector
Figure 4
A
B
C
