2-4-5 Decelerator Dimensions
For 2,000-r/min Servomotors (400 W to 1 kW)
*1. D6 is the maximum diameter of the decelerator body between the flange side and Servomotor side.
(Refer to the Outline Drawing) The value is given only when the diameter is larger than the diameters of these two sides.
Take heed of this when you mount the decelerator to the machine.
*2. Indicates set bolt.
Note 1. The standard shaft type is a straight shaft.
2. A model with a key and tap is indicated with “J” at of the model number. (Example:
R88G-HPG32A052K0BJ)
3. The diameter of the motor shaft insertion hole is the same as the shaft diameter of the corresponding
Servomotor.
4. You cannot use this type of Decelerator for the Servomotor with key.
5. The dimensional drawings in this document are for showing main dimensions only, and they do not give
the details of the product shape.
Servo-
motor
rated
output
Re-
duc-
tion
ratio
Model
Outline
drawing
Dimensions [mm]
LM LR C1 C2 D1 D2 D3 D4 D5
D6
*1
E F1 F2
400 W
(400 V)
1/5 R88G-HPG32A052K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/11 R88G-HPG32A112K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/21 R88G-HPG32A211K5B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/33 R88G-HPG32A33600SB 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/45 R88G-HPG32A45400SB 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
600 W
(400 V)
1/5 R88G-HPG32A052K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/11 R88G-HPG32A112K0B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/21 R88G-HPG32A211K5B 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/33 R88G-HPG32A33600SB 2 110 133 120 135 dia. 135 115 115 114 84 --- 98 12.5 35
1/45 R88G-HPG50A451K5B 2 123 156 170 170 dia. 190 115 165 163 122 --- 103 12 53
1 kW 1/5 R88G-HPG32A053K0B 1 107 133 120 130 x 130 135 145 115 114 84 --- 98 12.5 35
1/11 R88G-HPG32A112K0SB 1 107 133 120 130 x 130 135 145 115 114 84 --- 98 12.5 35
1/21 R88G-HPG32A211K0SB 1 107 133 120 130 x 130 135 145 115 114 84 --- 98 12.5 35
1/33 R88G-HPG50A332K0SB 2 123 156 170 170 dia. 190 145 165 163 122 --- 103 12 53
1/45 R88G-HPG50A451K0SB 2 123 156 170 170 dia. 190 145 165 163 122 --- 103 12 53
Servo-
motor
rated
output
Re-
duc-
tion
ratio
Model
Dimensions [mm]
G S T Z1 Z2
AT
*2
Key Tap
QK b h t1 M L
400 W
(400 V)
1/5 R88G-HPG32A052K0B 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/11 R88G-HPG32A112K0B 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/21 R88G-HPG32A211K5B 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/33 R88G-HPG32A33600SB 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/45 R88G-HPG32A45400SB 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
600 W
(400 V)
1/5 R88G-HPG32A052K0B 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/11 R88G-HPG32A112K0B 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/21 R88G-HPG32A211K5B 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/33 R88G-HPG32A33600SB 13 40 82 11 M8 × 10 M6 70 12 8 5 M10 20
1/45 R88G-HPG50A451K5B 16 50 82 14 M8 × 10 M6 70 14 9 5.5 M10 20
1 kW 1/5 R88G-HPG32A053K0B 13 40 82 11 M8 × 18 M6 70 12 8 5 M10 20
1/11 R88G-HPG32A112K0SB 13 40 82 11 M8 × 18 M6 70 12 8 5 M10 20
1/21 R88G-HPG32A211K0SB 13 40 82 11 M8 × 18 M6 70 12 8 5 M10 20
1/33 R88G-HPG50A332K0SB 16 50 82 14 M8 × 16 M6 70 14 9 5.5 M10 20
1/45 R88G-HPG50A451K0SB 16 50 82 14 M8 × 16 M6 70 14 9 5.5 M10 20
