2 - 127
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-4 External and Mounting Dimensions
2
2-4-8 Reactor Dimensions
R88A-PD4015
86
60
(1.2)
76
71
62
(18)
2-terminal M4 screw
Terminal block top view
UX
4-mounting hole
for M4 screw
105 max.
50 max. 36 max.
