3 - 9
3 Specifications
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
3-1 Servo Drive Specifications
3
3-1-2 Characteristics
Use a neutral grounded 400 VAC 3-phase power supply for the 400 VAC input models.
400-VAC Input Models
Servo Drive model
(R88D-)
1SN06F-ECT 1SN10F-ECT 1SN15F-ECT
Item 600 W 1 kW 1.5 kW
Input Main circuit Power sup-
ply voltage
3-phase 380 to 480 VAC (323 to 504 V)
*1
Rise time 500 ms max.
*2
Frequency
50/60 Hz (47.5 to 63 Hz)
*1
Control circuit Power sup-
ply voltage
24 VDC (21.6 to 26.4 V)
Current con-
sumption
*3
900 mA
Rated current
[A (rms)]
(Main circuit
power supply
voltage: 480
VAC)
3-phase 2.4 3.1 4.3
Output Rated cur-
rent
[A (rms)]
1.8 4.1 4.7
Maximum
current
[A (rms)]
5.5 9.6 14.1
Heating value [W] Main cir-
cuit
*4
20.2 52.1 77.5
Control cir-
cuit
20.4 20.4 20.4
Applicable Servomotor rated output
[W]
600 1,000 1,500
3,000-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
--- 1L75030C
1L1K030C
1L1K530C
2,000-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
1M40020C
1M60020C
1M1K020C 1M1K520C
1,500-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
--- --- ---
1,000-r/min Servomo-
tor (R88M-)
Batteryless
23-bit ABS
--- 1M90010C ---
Hold time at momentary power inter-
ruption
(Main circuit power supply voltage:
400 VAC)
10 ms (Load condition: rated output)
*5
Weight [kg] 3.4 3.4 3.4
To Next Page
