1 Features and System Configuration
1 - 10
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
R88D-1SN55H-ECT/-1SN75H-ECT/-1SN55F-ECT/-1SN75F-ECT
Charge lamp
Main circuit
connector B
(CNB)
Main circuit connector A
(CNA)
Motor connector
(CNC)
Control power
supply connector
(CND)
Control I/O connector
(CN1)
Status
indicators
7-segment
LED display
ID switches
Status indicators
EtherCAT
communications
connector
(ECAT IN CN10)
EtherCAT
communications
connector
(ECAT OUT CN11)
USB connector
Top view
terminal
