2 Models and External Dimensions
2 - 26
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Motor Power Cables (Standard Cable)
Applicable Servomotor
Model
Without brake wire With brake wire
100 V
200 V
3,000-r/min Servomotors of 100 W, 200 W, 400
W, and 750 W
*1
3 m R88A-CA1A003S ---
5 m R88A-CA1A005S ---
10 m R88A-CA1A010S ---
15 m R88A-CA1A015S ---
20 m R88A-CA1A020S ---
30 m R88A-CA1A030S ---
40 m R88A-CA1A040S ---
50 m R88A-CA1A050S ---
200 V 3,000-r/min Servomotors of 1 kW
2,000-r/min Servomotors of 1 kW
1,000-r/min Servomotors of 900 W
3 m R88A-CA1B003S R88A-CA1B003B
5 m R88A-CA1B005S R88A-CA1B005B
10 m R88A-CA1B010S R88A-CA1B010B
15 m R88A-CA1B015S R88A-CA1B015B
20 m R88A-CA1B020S R88A-CA1B020B
30 m R88A-CA1B030S R88A-CA1B030B
40 m R88A-CA1B040S R88A-CA1B040B
50 m R88A-CA1B050S R88A-CA1B050B
200 V 3,000-r/min Servomotors of 1.5 kW
2,000-r/min Servomotors of 1.5 kW
3 m R88A-CA1C003S R88A-CA1C003B
5 m R88A-CA1C005S R88A-CA1C005B
10 m R88A-CA1C010S R88A-CA1C010B
15 m R88A-CA1C015S R88A-CA1C015B
20 m R88A-CA1C020S R88A-CA1C020B
30 m R88A-CA1C030S R88A-CA1C030B
40 m R88A-CA1C040S R88A-CA1C040B
50 m R88A-CA1C050S R88A-CA1C050B
400 V 3,000-r/min Servomotors of 750 W, 1 kW, 1.5
kW, and 2 kW
2,000-r/min Servomotors of 400 W, 600 W, 1 kW,
1.5 kW, and 2kW
1,000-r/min Servomotors of 900 W
3 m R88A-CA1C003S R88A-CA1D003B
5 m R88A-CA1C005S R88A-CA1D005B
10 m R88A-CA1C010S R88A-CA1D010B
15 m R88A-CA1C015S R88A-CA1D015B
20 m R88A-CA1C020S R88A-CA1D020B
30 m R88A-CA1C030S R88A-CA1D030B
40 m R88A-CA1C040S R88A-CA1D040B
50 m R88A-CA1C050S R88A-CA1D050B
200 V
400 V
3,000-r/min Servomotors of 2 kW (200 V) and 3
kW (200 V/400 V)
2,000-r/min Servomotors of 2 kW (200 V) and 3
kW (200 V/400 V)
1,000-r/min Servomotors of 2 kW (200 V/400 V)
and 3 kW (400 V)
3 m R88A-CA1E003S R88A-CA1E003B
5 m R88A-CA1E005S R88A-CA1E005B
10 m R88A-CA1E010S R88A-CA1E010B
15 m R88A-CA1E015S R88A-CA1E015B
20 m R88A-CA1E020S R88A-CA1E020B
30 m R88A-CA1E030S R88A-CA1E030B
40 m R88A-CA1E040S R88A-CA1E040B
50 m R88A-CA1E050S R88A-CA1E050B
200 V 1,000-r/min Servomotors of 3 kW 3 m R88A-CA1F003S R88A-CA1F003B
5 m R88A-CA1F005S R88A-CA1F005B
10 m R88A-CA1F010S R88A-CA1F010B
15 m R88A-CA1F015S R88A-CA1F015B
20 m R88A-CA1F020S R88A-CA1F020B
30 m R88A-CA1F030S R88A-CA1F030B
40 m R88A-CA1F040S R88A-CA1F040B
50 m R88A-CA1F050S R88A-CA1F050B
