Omron R88D-1SN20F-ECT User Manual

2 - 123
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-4 External and Mounting Dimensions
2
2-4-8 Reactor Dimensions
R88A-PD2007
R88A-PD2015
78
55
(1.6)
68
76
67
(16)
2-terminal M4 screw
Terminal block top view
UX
4-mounting hole
for M4 screw
95 max.
40 max.50 max.
60 62
(18)
71
76
86
(1.2)
2-terminal M4 screw
Terminal block top view
UX
4-mounting hole
for M4 screw
50 max. 36 max.
105 max.
