Appendices
A - 126
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Event name
Main Power Supply Undervoltage (insufficient volt-
age between P and N)
Event code
08480000 hex
Meaning The main circuit power supply voltage fell below the operation guarantee range during Servo ON.
Source
EtherCAT Master Function Mod-
ule
Source details
Slave
Detection
timing
During Servo
ON
Error
attributes
Level
Minor fault
Recovery
Error reset
(after resetting
slave errors)
Log category
System log
Effects User program Continues. Operation Power drive circuit is OFF
Indicators
EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System
-defined
variables
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
Incorrect wiring of the main cir-
cuit power supply
If the power supply cables are not
wired to the main circuit power
supply terminals (L1, L2, L3), con-
nect them.
Check the wiring of the main circuit
power supply before use.
The low power supply voltage is
applied to the Servo Drive
Increase the power supply capac-
ity if it is small. Measure the
applied power supply voltage, and
apply the voltage according to the
specification.
Apply the voltage appropriate for
the Servo Drive.
The long time was set in Momen-
tary Hold Time and the voltage
was decreased momentarily
Remove the cause that momentar-
ily decreased the voltage.
Set a short time in the Momentary
Hold Time so as not to detect this
error due to a momentary
decrease in voltage.
Set an appropriate value in the
Momentary Hold Time.
Servo Drive failure If this event occurs again after you
performed all corrections shown
above, replace the Servo Drive.
None
Attached
information
None
Precautions/
Remarks
AL status code: -, Error No.: 1300 hex
To Next Page
