4-2-4 Terminal Block Wiring Procedure
The wire may not be inserted easily depending on the shape of the ferrule connected to it.
If this occurs, perform one of the following methods before inserting the wire.
• Change the direction of inserting the connector by 90º.
• Correct the shape of the ferrule with pliers.
