11 Adjustment Functions
11 - 26
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
This is the ratio of the frequency bandwidth at a damping factor of -3 [dB] relative to the center
frequency when the depth is “0.” This value should conform to the left column in the table below.
This is the I/O ratio at which the center frequency input is completely cut off at a set value of “0” and
completely passed at a set value of “100.” If the indication unit is [dB], this value should conform to the
right column in the table below.
11-7-2 Notch Filter Width and Depth
Width Setting
Depth Setting
Width Depth
Set value
Bandwidth/center frequency
Set value I/O ratio [%] Damping factor [dB]
0 0.50 0 0 (Cut off)
∞
10.59 11-40.0
20.71 22-34.0
30.84 33-30.5
41.00 44-28.0
51.19 55-26.0
61.41 1010-20.0
71.68 1515-16.5
82.00 2020-14.0
92.38 2525-12.0
10 2.83 30 30 -10.5
11 3.36 35 35 -9.1
12 4.00 40 40 -8.0
13 4.76 45 45 -6.9
14 5.66 50 50 -6.0
15 6.73 60 60 -4.4
16 8.00 70 70 -3.1
17 9.51 80 80 -1.9
18 11.31 90 90 -0.9
19 13.45 100 100 (Passed) 0.0
20 16.00
