1 Features and System Configuration
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
1-2 System Configuration
1
Motor power signal
I/O signal
Feedback signal
Linear Motor
 Commercial Product
 Serial Communications Cable
R88A-CRKE010SR
 90° phase difference output cable
supplied by the user
External Encoder Cable

Power cable
supplied by the user
Power Cable
 Iron-core family
External encoder
 Connector-Terminal Block
Conversion Unit
XW2-20G
 Cable
XW2Z-J-B34
Terminal Block and Cable
 Ironless family
Motor Coil Unit: R88L-EC-FW-
Magnet Track: R88L-EC-FM-
Motor Coil Unit: R88L-EC-GW-
Magnet Track: R88L-EC-GM-
