11-4
11-2 Warning List
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
11
Troubleshooting and Maintenance
11-2 Warning List
This is a function to output a warning signal before the protective function operates to notify the overload and other statuses in advance.
Set the warning output type to Warning Output Selection 1 (Pn440) and Waning Output Selection 2 (Pn441).
Precautions for Correct Use
Each warning automatically returns to the status before it occurred once the system recovers from the error.
However, for the time set in the Warning Latch Hold Time Selection (Pn627), the warning status will be held.
To clear the warning during the latch hold time, do so by performing the same procedures as alarm clear.
Warning List
*1. The "√" fields can be set to 1 to 10 s in the Warning Latch Hold Time Selection (Pn627) or to the no-
time limit setting. However, the battery warning is fixed with no time limit.
*2. Select the type of warning to be output in warning output 1 (WARN1) and warning output 2 (WARN2)
in the Warning Output Selection 1 (Pn440) and Warning Output Selection 2 (Pn441).If you set this to
0, all warning types will be output.Do not set it to a value other than above.
*3. Each warning detection can be masked using the Warning Mask Setting (Pn638). The corresponding
bits are shown in the table.
The warning detection is masked when the bit = 1.
Warning
number
Warning name Latch
*1
Warning condition
Warning Output Selection
(Pn440, Pn441)
*
2
Warning Mask
Setting (Pn638)
A0
Overload
warning
√
The load ratio is 85% or
more of the protection level.
1bit 7
A1
Excessive
regeneration
warning
√
The regeneration load
ratio is 85% or more of
the protection level.
2bit 5
A2
Battery warning
Always
fixed with
no time limit
Battery voltage is 3.2 V
or less. 3 bit 0
A3
Fan warning
√
The fan stops for 1
second.
4bit 6
A4
Encoder
communications
warning
√
Encoder communications
errors occurred in series
more than the specified
value.
5bit 4
A5
Encoder
overheating
warning
√
The encoder
temperature exceeded
the specified value.
6bit 3
A6
Vibration
detection
warning
√
Vibration is detected.
7bit 9
A7
Life expectancy
warning
Always
fixed with
no time limit
The life expectancy of
the capacitor or the fan
is shorter than the
specified value.
8bit 2
A8
External encoder
error warning
√
The external encoder
detected a warning.
9bit 8
A9
External encoder
communications
warning
√
The external encoder has
more communications errors
in series than the specified
value.
10 bit 10
