Omron S8JX-G Series

S8JX
11
S8JX-G S8JX-P
Common Precautions
Connections
Block Diagrams
Voltage
detection
Photocoupler
Drive control
Circuit
Overcurrent
detection
circuit
+V
−V
DC OUTPUT
Noise
filter
Inrush current
protection
Fuse
2.0 A
AC (L)
INPUT
AC (N)
Rectifier Smoothing
circuit
Rectifier/
Smoothing circuit
Overvoltage
detection circuit
S8JX-G01505@@ (15 W)
S8JX-G01512@@ (15 W)
S8JX-G01515@@ (15 W)
S8JX-G01524@@ (15 W)
Voltage
detection circuit
Photocoupler
Overvoltage
detection circuit
Drive control
circuit
Overcurrent
detection
circuit
+V
−V
DC OUTPUT
Rectifier/
smoothing circuit
Noise
filter
Inrush current
protection
Fuse:
2.0 A
AC (L)
INPUT
AC (N)
Rectifier Smoothing
circuit
S8JX-G01548@@ (15 W)
Voltage
detection
Photocoupler
Drive control
Circuit
Overcurrent
detection
circuit
+V
−V
DC OUTPUT
Noise
filter
Inrush current
protection
Fuse
3.15 A
AC (L)
INPUT
AC (N)
Rectifier Smoothing
circuit
Rectifier/
Smoothing circuit
Overvoltage
detection circuit
S8JX-G03505@@ (35 W)
S8JX-G03512@@ (35 W)
S8JX-G03515@@ (35 W)
S8JX-G03524@@ (35 W)
Voltage
detection circuit
Photocoupler
Overvoltage
detection circuit
Drive control
circuit
Overcurrent
detection
circuit
+V
−V
DC OUTPUT
Rectifier/
smoothing circuit
Noise
filter
Inrush current
protection
Fuse:
3.15 A
AC (L)
INPUT
AC (N)
Rectifier Smoothing
circuit
S8JX-G03548@@ (35 W)
