S8JX
41
S8JX-G S8JX-P
Common Precautions
Connections
Block Diagrams
Voltage
detection
Photocoupler
Overvoltage
detection circuit
Drive control
Circuit
Overcurrent
detection
circuit
+V
–V
DC OUTPUT
Noise
filter
Inrush current
protection
Fuse
2.5 A
AC(L)
INPUT
AC(N)
Rectifier
Smoothing
circuit
Rectifier/
Smoothing circuit
High-frequency
current regulation
S8JX-P050@@@@ (50 W)
Voltage
detection
Photocoupler
Overvoltage
detection circuit
Drive control
Circuit
Overcurrent
detection
circuit
+V
–V
DC OUTPUT
Noise
filter
Inrush current
protection
Fuse
6.3 A
AC(L)
INPUT
AC(N)
Rectifier
Smoothing
circuit
Rectifier/
Smoothing circuit
High-frequency
current regulation
S8JX-P100@@@@ (100 W)
S8JX-P150@@@@ (150 W)
