S8JX
39
S8JX-G S8JX-P
Common Precautions
Input specification 100 to 240 V input
Item Power ratings *1 300 W 600 W
Efficiency
5 V models 75% min. 76% min.
12 V models 77% min. 76% min.
24 V models 79% min. 78% min.
48 V models 78% min. 79% min.
Input
Voltage *2 100 to 240 VAC (allowable range: 85 to 264 VAC, 80 to 370 VDC *8)
Frequency *2 50/60 Hz (47 to 63 Hz)
Current *3
100 V input 4.5 A max. 8.7 A max.
200 V input 2.2 A max. 4.3 A max.
Power factor 0.9 min.
Harmonic current emissions Conforms to EN61000-3-2
Leakage current *3
100 V input 0.5 mA max.
200 V input 1 mA max.
Inrush current (for a
cold start at 25°C) *3
100 V input 17.5 A max.
200 V input 35 A max.
Output *4
Voltage adjustment range *5 −10% to 15% (with V. ADJ) (5 V, 48 V models: ±10%)
Ripple *3
2% (p-p) max.
3% (p-p) max. (for only 5 V type) *12
Input variation influence 0.4% max.
Load variation influence 0.8% max. (0 to 100% load, rated input voltage)
Temperature variation influence 0.05%/°C max.
Startup time 1,000 ms max.
Hold time *3 20 ms min.
Additional
functions
Overload protection *6 105% to 160%
of rated load current,
voltage drop, intermittent, automatic reset.
Overvoltage protection *7 Yes
Overheat protection Yes
Parallel operation Yes (up to 5 Power Supplies)
Series operation Yes (For up to two Power Supplies; external diodes required.)
Remote sensing Supported
Remote control Supported
Alarm detection indication Yes (color: red)
Alarm output Provided, open-collector output, 30 VDC max, 50 mA max.
Other
Ambient operating temperature
Refer to the derating curve in Engineering Data on page 44 (with no icing or condensation).
Storage temperature −25 to 75°C (with no icing or condensation)
Ambient operating humidity 25% to 85% (Storage humidity: 25% to 90%)
Dielectric strength
3.0 kVAC for 1 min. (between all inputs and outputs; detection current: 20 mA)
2.0 kVAC for 1 min. (between all inputs and PE terminals; detection current: 20 mA)
1.0 kVAC for 1 min. (between all outputs and PE terminals; detection current: 100 mA)
100 VAC for 1 min. (between all outputs and RC terminals; detection current: 100 mA)
500 VAC for 1 min. (between all outputs and ALM terminals; detection current: 20 mA)
Insulation resistance 100 MΩ min. (between all outputs and all inputs/PE terminals) at 500 VDC
Vibration resistance 10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
Shock resistance 150 m/s
2
, 3 times each in ±X, ±Y, ±Z directions *10
Output indicator Yes (Color: Green)
EMI
Conducted Emissions *3 Conforms to EN 55011 Group 1 Class B and based on FCC Class B *11
Radiated Emissions Conforms to EN 55011 Group 1 Class B *11
EMS
Electrostatic Discharge Conforms to EN61000-4-2
Radiated Electromagnetic Field Conforms to EN61000-4-3
Electrical Fast Transient/Burst Conforms to EN61000-4-4
Surge Conforms to EN61000-4-5
Conducted Disturbance Conforms to EN61000-4-6
Voltage Dips/Short Interruptions Conforms to EN61000-4-11
Approved standards *8
UL UR: UL 508 (Recognition)
*
13
UL Listed: UL508 (Listing)
*
14
UL UR: UL 60950-1 (Recognition)
cUR: CSA C22.2 No.107.1, CSA C22.2 No. 60950-1
EN/VDE: EN50178 (= VDE 0160) Over voltage category III,
EN 60950-1 (= VDE 0805 Teil 1)
(Terminal block: Based on DIN 50274 (VDE 0660-514))
SEMI
SEMI F47-0706 (200-VAC input)
Weight 1,200 g max.
*
9 1,800 g max.
*
9
