Omron S8JX-G Series User Manual

S8JX
49
S8JX-G S8JX-P
Common Precautions
S8JX-P15005 (150 W)
S8JX-P15005C (150 W)
3.5 dia.
(for mounting)
3.5 dia.
(for mounting)
8.2
9.5
10
13
Three, M3.5
Two, M4
Label
42
±1
13.5 max.
159
±1
5 max.
5
148
±0.5
Two, M3 (Depth 4 mm max.)
98
±0.5
15
3.5
(for mounting)
36
22
5
150
±0.5
92
±1
78.5
±0.5
7
Cover
3.5
(for mounting)
Panel mounting holes dimensions
Surface screw mounting
Side
Mounting
Bottom
Mounting
Two, M3
78.5
±0.5
148
±0.5
Two, M3
150
±0.5
