Omron S8JX-G Series

S8JX
54
S8JX-G S8JX-P
Common Precautions
Mounting Bracket Provided with Front-mounting Power Supplies a
DIN Rail (Order Separately)
Note: 1. If there is a possibility that the Unit will be subject to vibration or shock, use a steel DIN Rail. Otherwise, metallic filings may result from
aluminum abrasion.
2. If the Unit may be subjected to sliding to either side, attach an End Plate (model PFP-M) on each side of the Unit.
Terminal Cover (Order Separately)
Replacement Fan (sold separately)
S82Y-J00F Front-mounting
Bracket
Front-mounting Method
Temporarily attach the enclosed mounting
bracket as shown in the illustration on the right,
hook the holes (parts a) in the Power Supply on
hooks on the mounting bracket (parts b), and
secure the Power Supply with two mounting
screws.
Terminal Cover model
Applicable Power Supply and
applicable location
S82Y-JTC1
S8JX-P50W
S8JX-P100W
S8JX-P150W 12-V, 24-V or 48-V output
Product Model
Replacement fan unit for 300-W models S82Y-JXP30FAN
Replacement fan unit for 600-W models S82Y-JXP60FAN
Dimensions
Mounting
dimensions
11
9
1.5
60
11
20
5
31.5
20.5
15
4.7
4.6
4.6 15
±0.2
74
Two, 3.5 dia.
t = 1.0
Material: Stainless steel
Two, M3
20
60
b
b
a
a
Mounting
bracket
Note: Mounting screws are not
provided.
Mounting Rail
(Material: Aluminum)
4.5
15 25 25
10 10
1,000 (500) ∗
25 25 15 (5) *
35
±0.3
7.3
±0.15
27
±0.15
1
* Value in parentheses are for PFP-50N.
Model
PFP-100N
PFP-50N
Mounting Rail
(Material: Aluminum)
4.5
15 25 25
10 10
1,000
25 25 15
1 1.5
29.2242735
±0.3
16
Model
PFP-100N2
1.3
4.8
35.5
35.5
1.8
1.8
M4 spring
washer
10
6.2
1
50
M4 × 8
panhead
screw
11.5
10
End Plate
Model
PFP-M
