S8JX
9
S8JX-G S8JX-P
Common Precautions
Input specification 100/200 V (Selected)
Item Power ratings *1 300 W 600 W
Efficiency
5 V models 71% min. 72% min.
12 V models 75% min. 78% min.
24 V models 82% min. 80% min.
48 V models 82% min. 80% min.
Input
Voltage *2
100 to 120 VAC (allowable range: 85 to 132 VAC)
200 to 240 VAC (allowable range: 170 to 264 VAC)
(Switchable)
Frequency *2 50/60 Hz (47 to 450 Hz)
Current *3
100 V input 8A max.
16 A max.(5V, 12V, 48V)
14 A max.(24V)
200 V input 4.5 A max.
9 A max.(5V, 12V, 48V)
8 A max.(24V)
Harmonic current emissions ---
Leakage current *3
100 V input 0.5 mA max.
200 V input 1 mA max.
Inrush current (for a
cold start at 25°C) *3
100 V input 25 A max. 30 A max.
200 V input 50 A max. 60 A max.
Output *4
Voltage adjustment range *5 −10% to 15% (with V. ADJ) (48-V models: ±10%)
Ripple *3
2.8% (p-p) max.(5V) *6
2% (p-p) max.(12V, 24V, 48V)
3.8% (p-p) max.(5V) *6
2% (p-p) max.(12V) *6
2% (p-p) max.(24V, 48V)
Input variation influence 0.4% max.
Load variation influence 0.8% max. (0 to 100% load, rated input voltage)
Temperature variation influence 0.05%/°C max.
Startup time 650 ms max. 500 ms max.
Hold time *3 20 ms min.
Additional
functions
Overload protection *7
105% to 175%
of rated load current, Inverted L voltage drop,
the circuit will be shut OFF when the
overload exceeds 5 s.
(5V, 12V)
*
10
voltage drop, intermittent, automatic reset.
(24V, 48V)
105% to 175% of rated load current, Inverted
L voltage drop, the circuit will be shut OFF
when the overload exceeds 5 s.
*
10
Overvoltage protection *8
Yes (5V, 12V)
*
10
Yes (24V, 48V)
*
10
Yes *10
Overheat protection
Yes (5V, 12V)
*
10
N0 (24V, 48V)
*
10
Yes *10
Parallel operation Yes (up to 5 units)
Series operation Yes (For up to two Power Supplies; external diodes required.)
Protective circuit operation indicator
Yes (color: red) (5V, 12V)
No (24V, 48V)
Yes (color: red)
Other
Ambient operating temperature
Refer to the derating curve in Engineering Data on page 17 (with no icing or condensation).
Storage temperature −25 to 65°C (with no icing or condensation)
Ambient operating humidity 25% to 85% (Storage humidity: 25% to 90%)
Dielectric strength
3.0 kVAC for 1 min. (between all inputs and outputs; detection current: 25 mA)
2.0 kVAC for 1 min. (between all inputs and PE terminals; detection current: 25 mA)
1.0 kVAC for 1 min. (between all outputs and PE terminals; detection current: 25 mA)
Insulation resistance 100 MΩ min. (between all outputs and all inputs/PE terminals) at 500 VDC
Vibration resistance 10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
Shock resistance 150 m/s
2
, 3 times each in ±X, ±Y, ±Z directions
Output indicator Yes (Color: Green)
EMI
Conducted Emissions *3 Conforms to EN 55011 Group 1 Class A and based on FCC Class A
*
11
Radiated Emissions Conforms to EN 55011 Group 1 Class A
*
11
*
12
EMS
Electrostatic Discharge Conforms to EN61000-4-2
Radiated Electromagnetic Field Conforms to EN61000-4-3
Electrical Fast Transient/Burst Conforms to EN61000-4-4
Surge Conforms to EN61000-4-5
Conducted Disturbance Conforms to EN61000-4-6
Voltage Dips/Short Interruptions Conforms to EN61000-4-11
Approved standards *13
UL UR: UL 508 (Recognition), UL 60950-1 (Recognition)
cUR: CSA C22.2 No. 60950-1
EN/VDE: EN50178 (= VDE 0160), Over voltage category III, EN 60950-1 (= VDE 0805 Teil 1)
(Terminal block: Based on DIN 50274 (VDE 0660-514))
Weight *9
1,800 g max. (5V, 12V)
1,600 g max. (24V, 48V)
2,500 g max.
