S8VK-S
6
Inrush current
protection circuit
Overcurrent
detection circuit
+V
+V
−V
−V
−V
DC OUTPUT
Rectifier/
smoothing circuit
Smoothing
circuit
Harmonic current
suppression circuit
(Power factor improvement)
Rectifier
Noise
filter
Fuse
250 VAC
8.0 A
HBC
AC (L)
INPUT
AC (N)
Drive control
circuit
DC LOW OUT
Low-voltage
detection output
Overcurrent
circuit
Current
detection circuit
Voltage
detection circuit
Overvoltage
detection circuit
Photocoupler
S8VK-S24024 (240 W)
Overcurrent
detection circuit
+V
+V
−V
−V
−V
DC OUTPUT
Rectifier/
smoothing
circuit
Smoothing
circuit
Harmonic current
suppression circuit
(Power factor improvement)
Rectifier
Noise
filter
Fuse
250 VAC
12.0 A
HBC
AC (L)
INPUT
AC (N)
Drive control
circuit
DC LOW OUT
Low
-
voltage
detection output
Overcurrent
circuit
Current
detection circuit
Voltage detection
circuit
Overvoltage
detection circuit
Photocoupler
Inrush current
protection circuit
S8VK-S48024 (480 W)
