Omron S8VM Series

22 Switch Mode Power Supply S8VM
Typical Values
� For Reference Only
Note: 1. Refer to the Engineering Data section on page 7 to 8 for details.
2. The typical values indicate the values for an input condition of 230 VAC. All items are measured at a frequency of 50 Hz.
Power
ratings
15 W 30 W 50 W 100 W 150 W
Item
Efficiency 5-V models 78% 81% 85% 87% 87%
12-V models 81% 84% 84% 87% 87%
15-V models 81% 84% 84% 87% 87%
24-V models 82% 86% 84% 88% 88%
Input Current 230 V input 0.20 A 0.39 A 0.31 A 0.61 A 5 V: 0.73 A
12 V/15 V/24 V: 0.83 A
Leakage current 230 V input 0.30 mA 0.35 mA 0.35 mA 0.35 mA 0.35 mA
Inrush current
(See note 1.)
230 V input 28 A 32 A 32 A 32 A 32 A
Output Ripple f=20MHz
measuring
5 V: 0.60% (p-p) 5 V: 0.60% (p-p) 5 V: 2.39% (p-p) 5 V: 2.10% (p-p) 5 V: 1.97% (p-p)
12 V: 0.08% (p-p) 12 V: 0.14% (p-p) 12 V: 0.56% (p-p) 12 V: 0.69% (p-p) 12 V: 0.67% (p-p)
15 V: 0.07% (p-p) 15 V: 0.12% (p-p) 15 V: 0.36% (p-p) 15 V: 0.60% (p-p) 15 V: 0.54% (p-p)
24 V: 0.07% (p-p) 24 V: 0.12% (p-p) 24 V: 0.22% (p-p) 24 V: 0.27% (p-p) 24 V: 0.32% (p-p)
f=100MHz
measuring
5 V: 0.77% (p-p) 5 V: 0.88% (p-p) 5 V: 2.47% (p-p) 5 V: 2.42% (p-p) 5 V: 2.54% (p-p)
12 V: 0.20% (p-p) 12 V: 0.20% (p-p) 12 V: 0.58% (p-p) 12 V: 0.78% (p-p) 12 V: 0.75% (p-p)
15 V: 0.12% (p-p) 15 V: 0.18% (p-p) 15 V: 0.37% (p-p) 15 V: 0.68% (p-p) 15 V: 0.63% (p-p)
24 V: 0.10% (p-p) 24 V: 0.18% (p-p) 24 V: 0.23% (p-p) 24 V: 0.31% (p-p) 24 V: 0.37% (p-p)
Start up time
(See note 1.)
at 100% load 270 ms 280 ms 460 ms 460 ms 460 ms
Hole time
(See note 1.)
at 100% load 5 V: 211 ms 5 V:187 ms 5 V: 43 ms 5 V: 40 ms 5 V: 41 ms
12 V: 213 ms 12 V:200 ms 12 V: 38 ms 12 V: 43 ms 12 V: 41 ms
15 V: 221 ms 15 V:204 ms 15 V: 42 ms 15 V: 40 ms 15 V: 37 ms
24 V: 216 ms 24 V:197 ms 24 V: 30 ms 24 V: 36 ms 24 V: 33 ms
