Switch Mode Power Supply S8VM 1
Switch Mode Power Supply
S8VM (15/30/50/100/150-W Models)
Power Supply Featuring OMRON’s Unique,
New Undervoltage Alarm Function with
Compact Body Contributing to Machine
Downsizing
• New undervoltage alarm function assists in determining causes
of errors (S8VM-@@@24A
@/P@ only).
• Broad range of possibilities with 5 capacities and 20 models to
choose from.
• RoHS compliant, including lead-free construction.
• Safety standards:
UL508/60950-1/1604, CSA C22.2 No. 14/No. 60950-1/No. 213,
EN50178, EN60950-1
• Harmonic current emissions: Conforms to EN61000-3-2.
• New, attentive design prevents screws from falling out of
terminal block.
• Finger protection prevents electric shock.
• DIN Rail mounting.
Note: Refer to Precautions for Safe Use on page 19.
Note: 300- to 1,500-W models will be released in 2006.
Model Number Structure
� Model Number Legend
Note: Not all combinations are possible. Please refer to the list of models in Ordering Information on page 2.
Note: 1. The front-mounting type cannot be used as a back-mounting type. For a back-mounting configuration, use a DIN Rail mounting bracket
type.
2. The housing and terminal of the connector for the undervoltage alarm output are provided with the S8VM-05024A
@/P@, S8VM-
10024A
@/P@ and S8VM-15024A@/P@.
1 2
3
4
S8VM- @@@@@@@
1. Power Ratings
015: 15 W
030: 30 W
050: 50 W
100: 100 W
150: 150 W
2. Output voltage
05: 5 V
12: 12 V
15: 15 V
24: 24 V
3. Configuration/function
None: Open-frame type Standard type
C: Covered type Standard type
A: Covered type Undervoltage alarm type (Sinking)
(See note.)
P: Covered type Undervoltage alarm type (Sourcing)
(See note.)
4. Configuration
None Front-mounting type
D DIN Rail mounting bracket type
