Omron S8VS-24024A -F Series

S8VS
12
Photocoupler
Noise filter
AC (L)
INPUT
AC (N)
Photocoupler
Yrs/kh
Common
Display circuit Switch
Sinking type
(S8VS-18024A-@, S8VS-18024B-@)
Sourcing type
(S8VS-18024AP-@, S8VS-18024BP-@)
Type with no alarm output
(S8VS-18024BE-@)
Fuse 6.3 A
Inrush current
protection
circuit
Rectifier
Smoothing
circuit
Harmonic current
suppression circuit
(Power factor improvement)
Drive control
circuit
Overcurrent
detection circuit
Rectifier/smoothing circuit
Voltage
detection circuit
Overvoltage
detection circuit
+V
−V
DC OUTPUT
Rectifier/smoothing circuit
Arithmetic
operation circuit
Alarm
DC Low
S8VS-18024A@-@ (180 W)
S8VS-18024B@-@ (180 W)
S8VS-18024BE-@ (180 W)
S8VS-18024-@ (180 W)
Photocoupler
I
NPUT
Rectifier/smoothing circuit
+V
−V
DC OUTPUT
Fuse
6.3 A
AC (L)
AC (N)
Voltage
detection circuit
Noise filter
Drive control
circuit
Overvoltage
detection circuit
Overcurrent
detection circuit
Inrush current
protection
circuit
Rectifier
Smoothing
circuit
Harmonic current
suppression circuit
(Power factor improvement)
