Omron S8VS-24024A -F Series User Manual

S8VS
13
Noise filter
AC (L)
INPUT
AC (N)
Photocoupler
Photocoupler
Yrs/kh
Common
Display circuit Switch
Sinking type
(S8VS-24024A-@, S8VS-24024B-@)
Sourcing type
(S8VS-24024AP-@, S8VS-24024BP-@)
Type with no alarm output
(S8VS-24024BE-@)
Fuse 8.0 A
Inrush current
protection
circuit
Rectifier
Smoothing
circuit
Harmonic current
suppression circuit
(Power factor improvement)
Overcurrent
detection circuit
Drive control
circuit
Voltage
detection circuit
Overvoltage
detection circuit
Rectifier/smoothing circuit
Rectifier/smoothing circuit
Arithmetic
operation circuit
Alarm
DC Low
+V
+V
−V
−V
DC OUTPUT
S8VS-24024A@-@ (240 W)
S8VS-24024B@-@ (240 W)
S8VS-24024BE-@ (240 W)
S8VS-24024-@ (240 W)
DC OUTPUT
INPUT
Inrush current
protection
circuit
Harmonic current
suppression circuit
(Power factor improvement)
Photocoupler
Rectifier/smoothing circuit
+V
−V
Fuse
8.0 A
AC (L)
AC (N)
Voltage
detection circuit
Noise filter
Drive control
circuit
Overvoltage
detection circuit
Overcurrent
detection circuit
Rectifier
Smoothing
circuit
